MINING (PLATINUM)
Sonic SDC450 track drill, Sonicor 50K Drill Head: SDC designed a purpose built drill and Arctic enclosure to suit the extreme cold conditions for a Platinum Mine near Khabarovsk, Russia. Taking large samples in permafrost ground (river bed gravel/cobble)
EXPLORATION (OFF SHORE SAMPLING)
Sonic SDC550 track drill, Sonicor 50K Drill Head: Exploration drilling off the coast of New Zealand. Sonic Drill Corp. designed and developed a unique "active heave compensation system" used for maintaining constant weight on the bit during vertical motion of the floating offshore platform. SDC also designed the drill platform which secured the drill while hydraulically shifting it ON/OFF the moon pool.
RELIABILITY
January 2010, a large scale high production open pit gold mine in Lima, Peru reported an impressive 9,255 vibrator hours and 11,000.25 diesel engine hours on a Sonic SDC550 track drill which was delivered in August 2006. Performance figures well in excess of the standard warranty for the head and engine. The drill was used to sample overburden leach pads 24/7. A real world testament to the proven reliability, quality and performance of the Sonicor 50K Drill Head. Only available from the pioneers of Sonic Technology - Sonic Drill Corporation.
ENVIRONMENTAL (SITE ASSESSMENT)
Sonic SDC390-14, Sonicor 50K Drill Head: Sampling a limited access site which at one time was a bulk oil storage tank farm and railcar transfer station.
EXPLORATION (SWAMP CARRIER)
Sonic SDC550, Sonicor 50K Drill Head: Exploration project in South Africa.
GEOTECHNICAL
Sonic SDC550-24, Sonicor 50K Drill Head: Geotechnical & SPT project on the out skirts of Las Vegas.
EXPLORATION (HELI-PORT)
Sonic Heli-Portable Drill, Sonicor 33K Drill Head: 6 heli-port units built for a large oil company exploration project in Australia.
ENVIRONMENTAL (SITE ASSESSMENT)
Sonic SDC350 track drill, Sonicor 33K Drill Head: Sampling an industrial site in Lyon, France.
MINING (IRON ORE)
Sonic SDC550 track drill, Sonicor 50K Drill Head: Sampling Iron Ore for a Mine in South Africa.
EXPLORATION (LITHIUM)
Probe 200 track drill, EP26 drill head: Sampling the Solares in Chile for Lithium at 16,400 ft. above sea level. This powerful little machine reached sample depths of 157' in hard ground (crystallized salt).
MINING (ALLUVIAL DIAMONDS)
Sonic SDC550-24 track drill, Sonicor 50K Drill Head: Sampling Pleistocene beaches for Alluvial Diamonds in the Southern Coastal Mines on the Namibian Coast.
GEOTHERMAL
Sonic SDC450 (foreground) and SDC450 (background) long stroke track drills, Sonicor 50K Drill Heads: Drilling geothermal wells for a Waste Water Treatment Facility in Washington State. 119 x 200 ft. boreholes in consolidated rock and sand formations.
EXPLORATION (BAUXITE)
Sonic SDC550, Sonicor 50K Drill Head: Drilling though silica sand overburden in the jungles of Guyana, sampling Bauxite in the historical coastal bauxite belt. The drill operates around the clock, 24/7 and collects high-grade Bauxite ore for a producer and supplier of calcined bauxite.
DRILL RIGS/CONSTRUCTION
Sonicor 33K Drill Head fitted onto a Casagrande C8: Drilling and compensation grouting during excavation under apartment buildings. 4-1/2" x 160' deep borings. Relative uplift is measured using an electronic level gauge.
